Aluminium Foil Container Machine

Aluminium Foil Container Machine

Technical Specification

Machine Type: Automatic

Control Panel: Digital

Lane Support: Single Cavity

Req. Machine Dimension: (L x W x H) 11 x 5 x 7.5 Feet

Container Size: 100 – 1000 ml

Suitable Foil: 25 – 50 Microns

Production Capacity: 50 pcs / min

Motor Capacity: 5.5 HP

Total Power: 7.5 – 8 kw

Running Load: 5 kw

Req. worker: 1 Operator + 1 Helper

Air Compressor: 3 HP / 5 HP

Req. Std. Space: About 800 – 1000 Sq. Ft.

Machine Set Weight: 3 Ton

Counting Stacker: Optional

Scrap Blower: Optional

Feeder Machine (Automatic With PLC Touch Screen): One Set Included With Machine

Mould Of 250 Cavity: One Set Included With Machine

Pneumatic Press: One Set Included With Machine

Compressor: One Set Included With Machine
